Capacity
- Safe Working Load |
Kg. |
500 |
1000 |
2000 |
2500 |
3000 |
5000 |
8000 |
10000 |
|
Number
of falls of load chain |
No. |
1 |
1 |
2 |
1 |
3 |
2 |
3 |
4 |
|
Dimensions |
|
|
|
|
|
|
|
|
|
|
A
hook suspension |
mm |
335 |
400 |
461 |
530 |
585 |
805 |
880 |
950 |
|
hung-in (With Trolley) |
mm |
- |
- |
- |
- |
695 |
895 |
1010 |
1080 |
|
hung-in (indef M trolley, range 1 & 2) |
mm |
365 |
430 |
500 |
560 |
- |
- |
- |
- |
|
hung-in (indef M trolley, range 3) |
mm |
405 |
470 |
540 |
605 |
- |
- |
- |
- |
|
close-lift (Mono Block) |
mm |
- |
- |
- |
- |
600 |
800 |
950 |
985 |
|
close-lift (ranges 1&2) (Mono Block) |
mm |
300 |
345 |
446 |
425 |
- |
- |
- |
- |
|
close-lift (ranges 3) (Mono Block) |
mm |
340 |
385 |
486 |
470 |
- |
- |
- |
- |
|
B |
mm |
155 |
180 |
180 |
238 |
268 |
280 |
430 |
480 |
|
C |
mm |
144 |
153 |
153 |
209 |
153 |
209 |
220 |
220 |
|
H
hook admittance |
mm |
27 |
32 |
32 |
42 |
42 |
51 |
67 |
75 |
|
• Minimum clear depth of Beam |
mm |
127 |
127 |
150 |
150 |
150 |
225 |
275 |
275 |
|
• Minimum radius of track curve |
mm |
1.5 |
1.5 |
1.5 |
1.5 |
1.5 |
2.6 |
3.2 |
3.2 |
|
• Weight: hook suspension unit with
chain for standard 3m hook-to-hook |
kg |
10 |
13 |
19 |
29 |
30 |
59 |
94 |
130 |
|
• Additional weight for extra height of
lift, per meter |
kg |
1.4 |
1.8 |
2.6 |
3.5 |
3.6 |
5.7 |
7.9 |
10.1 |
|
• Effort on hand chain to raise full
working load |
kg |
28 |
30 |
33 |
37 |
33 |
41 |
46 |
43 |
|
• Velocity ratio (movement of hand
chain relative to load chain) |
|
27:1 |
45:1 |
90:1 |
78:1 |
135:1 |
156:1 |
234:1 |
312:1 |
|
• Safety factor |
|
4:1 |
4:1 |
4:1 |
4:1 |
4:1 |
4:1 |
4:1 |
4:1 |
