Our Products :




        DNF7 - Air-Insulated Switchgear up to 40.5kV :



The DNF7 is a withdrawable air insulated switchgear using either vacuum or SF6 circuit breakers, that can be used in a wide range of applications including industry, utility and Oil & Gas.


  •  Ratings up to 40.5 kV / 2500 A / 31.5 kA

  •  Loss of Service Continuity - LSC 2B PM

  •  Enhanced Internal Arc Classification (IAC) AFLR duration 1 second

  •  Designed and tested to the latest IEC62271-200



        F400-F400xe - Air-Insulated Metalclad Switchboard up to 40.5 kV :


Its design ensures an excellent level of reliability. Network diagnosis and maintenance have a reduced impact on power distribution. Universal symbols, position indicators and mechanical and electrical interlocks guide the operator.


  •  The F400 range offers a full choice of perfectly adaptable, pre-designed functional units

  •  The F400 range, in association with Sepam digital control units, is designed to interface with new or existing supervision systems

  •  The F400 offer is composed of :


        •  the F400 which covers all performances up to 40.5kV - 2500A - 40kA/3s

        •   the F400xe, a restricted offer optimised for the performances 36kV - 2500A - 25kA/3s



        GenieEvo - Compact Modular Switchboard 3.3 - 13.8 kV :


GenieEvo is a metal partitioned MV switchgear using a fixed de-mountable vacuum circuit-breaker in series with a solid insulated disconnector.


  •  Combined with a wide range of protection modules it offers a simple and highly reliable solution for virtually any application. :


        •  Vacuum technology

        •  Rated voltage: 13.8 kV

        •  Rated short time withstand: 25 kA/3s

        •  Rated peak making current: 67.5 kA

        •  Vacuum technology

        •  Rated voltage: 13.8 kV



        Masterclad - Air-Insulated Primary Switchboard up to 27 kV :


  •  MASTERCLAD is a metal enclosure switchgear assembly that provides maximum user safety.


  •  Designed using proven techniques, high performance breaking devices, digital protection and control system.


  •  High level protection of people: each section is isolated from the others by earthed metal partitions, safety interlocking.


  •  Safety operation: simple use, safety system that prevents all unauthorised operation.


  •  Performances :

      •  Technology: Vacuum

      •  Standard: NEMA

      •  Rated voltage: 27kV

      •  Busbar system: Single

      •  Rated current busbar: 2000A

      •  Rated operational current: 2000A

      •  Rated peak withstand current: 40kA



        MCset 17.5 kV - Withdrawable Circuit Breakers up to 17.5 kV :


  •  High level protection of people: each compartment is isolated from the others by earthed metal partitions, safety interlocking


  •  Reduced maintenance and probability of failure: monitoring of temperature rise, indication of the fault zone


  •  Safety operation: simple use, safety interlock that prevents all unauthorized operation.


  •  Designed using proven techniques


  •  High performance breaking devices (SF6 technology)


  •  Digital protection and control system



        MCset 24 kV - Medium Voltage switchgear (AIS type): SF6 withdrawable circuit-breaker up to 24 kV :


  •  High level protection of people: each section is isolated from the others by earthed metal partitions, safety interlocking


  •  Reduced maintenance and probability of failure: monitoring of temperature rise, indication of the fault zone


  •  Safety operation: simple use, safety system that prevents all unauthorised operation


  •  High performance breaking devices (SF6 technology)


  •  Digital protection and control system


  •  Designed and tested for internal arc resistance
