INTRODUCTION:

'KBS Power Electronics' is a pioneering leader with experience and expertise in the management and application of a wide range of CEEC Servo Controlled Voltage Stabilizers in the country.

'KBS' is extensively engaged in manufacturing and marketing an incredible portfolio of products and services to fulfill almost every need in stabilization of electrification.

'KBS' commitment to creative excellence is effectively realized by the collective effort of a strong workforce at its Kolkata establishments. Relentlessly tracking the protocols crucial to meaningful and responsible business. Quality, Technology, Productivity & Customers Service. 'KBS' is fully committed to expand the strategic horizons in its chosen field, developing new ideas, evolving new capabilities and programming new actions to dynamically techno-synthesize the future to come.

FEATURES:

• No warm-up time ; immediate response after switching on ; plug in module for Control Circuit.
• 1.0% regulation from no load to full load for complete range of input voltage.
• 100% capacity utilization up to 45 degree C and with moderating – up to 65 degree C: Fully tropicalised.
• No wave from distortion is introduced by the stabilizer.
• Load power Factor variations do not affect performance.
• Manual control facility
• Precision voltmeter to monitor both input and output voltage.
• Easy of serviceability through interchangeable plug-in control circuit module.
• Use of A.C. motor enables a better regulation and correction speed is constant throughout the entire range 25V of models.
• Reliable advance I.C. circuitry for fast switching and better response with almost zero overshooting.
• In three phase models three single phase units are connected in star configuration.
• Automatic output trip (automatically resettable) at preselected output voltage in case of ;

SPECIAL FEATURES:

1. deviation greater than +/_ 1% at the preselected output voltage,
2. mains input variation greater than the speed of correction of the unit,
3. failure of varriac or any other control parts.

* CEEC brand offers servo Voltage Stabilizers for 3-Phase systems. These usually three single-phase Servo Stabilizers connected in STAR configuration for 3 Phase applications with individual sensing for each phase and to provide constant output in each phase with unbalanced supply or unbalanced load.

* For 3 Phase Units output for single phasing or any conditions specified above.

* Spike suppressor and output sensed trip circuit for high and low voltage are provided at an extra costs, this circuit trip off the load on deviation of 1% of the output voltage.

TECHNICAL SPECIFICATION (maximum range of our stabilizer)

Features

( Single phase models:)
Input Voltage : 170v.to 265V/130V to 280V./100V to 320V
Output Voltage : 230 Volts/240V.(Nominal)
Regulation : +/- 1% (both on line and load)
Input Wave Form (necessary for 1% regulation) : Total sinusoidal, distortion less than 5 %
Frequency range : 47 to 53 Hz.
Waveform Distortion : Nil
Effect of load power factor : Nil
Speed of correction : 25V. Volts/Sec. (in all range)
Settability of output voltage : 220V to 240 V
Capacity : 0.5KVA to 33 KVA
(Three Phase models)
Input Voltage : 294V.to 465V/250V to 480V/225V to 480V, 173 V to 520V
Output Voltage : 398 Volts/415 Volts (Nominal)
Regulation : +/-1% (both line and load)
Settability of Output Voltage : 380V to 415V
Capacity : 3 KVA to 1000 KVA
All other specification adheres to single phase units
