Authorised Stockists of :   MATRIX, UNISTAR, EPCOS, MEHER

Range-: Range from 1 KVAR - 25 KVAR - Application Ideally Suitable for P.F. Corrections in industries, any Electrical Machinery.

Matrix Power Capacitors :

MPP-SH (Normal Duty) :

Product Range :

Box type - 1 KVAr-50KVAr

Cylindrical - 1 KVAr-25KVAr

Applications :

IPFC Panels.
Fixed compensations with Induction motors through
Contactor Switching. Fixed compensations where load variations are less than 10%.

SPECIFICATION :

• Rated voltage : 440 volts standard
• Over current : 1.5 In*
• Over voltage : Un+10%(upto12hrs)
• Cap tolerance : 0.95 Cn to 1.1 Cn
• Degree of protection : IP 42*
• Dielectric losses : 0.2 watts per KVAr
• Capacitor loss (tan d) : 0.00115
• Temp category : D (Max 55 Degrees C)
• Container type : 2 colour powder coated for box type Al can for cylindrical range.

• Safety devices : Overpressure Disconnector / Discharge Resistor
• Dielectric : Imported base PP film

• Dielectric stress level : <60 volts / micron*
• Peak transient : <=100ln
• Inductor coil : Provided in 20 KVAr onwards.
• Switching Life : 5000 switchings per Year

MPP-HD (Heavy Duty) :

Product Range :

Box type - 5 KVAr - 25KVAr

Applications :

IPFC Panels for any type of stringent applications in Steel / Sugar / Paper Indutry.

SPECIFICATION :

• Rated voltage : 440 volts
• Over current : 1.8 In*
• Over voltage : Un+15%(upto12hrs)
• Cap tolerance : 0.95 Cn to 1.1 Cn
• Degree of protection : IP 42*
• Dielectric losses : 0.2 watts per KVAr
• Temp category : D (Max 55 Degrees C)
• Container type : 2 colour powder coated .

• Safety devices : Overpressure Disconnector / Discharge Resistor
• Dielectric : Imported base PP film

• Dielectric stress level : <40 volts / micron*
• Peak transient : 200ln
• Inductor coil : Provided in 20 KVAr onwards.
• Switching Life : Approx 10000 switchings per Year*

MP-HL (Metallized Paper-High Life) :

Product Range :

Box type - 10 KVAr - 25KVAr

Applications :

IPFC Panels. Application where load variations are more than 20%. Exclusively designed for sugar Industries.

SPECIFICATION :

• Rated voltage : 440 volts
• ISI License No.: CM/L - 8723484
• Technical Specs : As Per IS13340
• Rated voltage : 440 volts
• Over current : 2.0 In*
• Over voltage : Un+10%(upto12 hrs)
• Cap tolerance : 0.95 Cn to 1.1 Cn
• Degree of protection : IP 42*
• Dielectric losses : 0.1 watts per KVAr
• Temp category : D (Max 60 Degrees C)
• Container type : 2 colour powder coated .

• Safety devices : Discharge Resistor ( 50 volts in 47 sec)
• Dielectric : Imported DMP + PP film

• Dielectric stress level : <40 volts / micron*
• Peak transient : 200ln
• Inductor coil : Provided in all ratings
• Switching Life : 12000 switchings per Year
• Dielectric stress level : Very low
