SPECIFICATIONS
of MODEL 4 |
Construction: |
Tubular,
rigid, electrostatically powder coated
steel sections. (COMFORT - S has stainless
steel construction). |
Table
Top: |
Stainless
Steel (597 X 360 mm). |
Mobility: |
Four
large diameter anti-static castor wheels
with ball bearings. |
Cylinder
Yokes: |
Gas
Specific (pin-indexed) Yokes with sliding
stainless steel clamping bars for easy
handling.
Two Each for oxygen and nitrous oxide
(5 litre water capacity) (Cylinders to
be ordered separately). |
Pressure
Gauges: |
Large diameter (63 mm) - two each for
oxygen and nitrous oxide, fitted at convenient
angle for high visibility and clarity. |
Regulators: |
Designed
for higher efficiency and reliability;
two each for oxygen and nitrous oxide.
Nitrous oxide regulators are pressurised
to minimise the risk of administering
100% nitrous oxide. |
Rotameter: |
Long
(230 mm) rotating bobbing flowmeters calibrated
in double/triple scale for accuracy and
clarity in reading.
Oxygen: 100 ml/min to 8 liters/min.
Nitrous oxide: 200 ml/min to 12 liters/min. |
Oxygen
Failure
|
Pneumatic device which activates audible
(Oxygen failure alarm for a minimum of
7 seconds) when warning device) oxygen
suply pressure fails to 205 kpa. |
Warning
Device: |
Vaporizers: |
One
Planum type vaporizer for Ether supplied
as standard. Space for one or more vaporizers
of choice. |
Non-return
cum pressure Relief valve |
Minimises
risk of backflow of gases;blows off when
pressure exceeds 200 cm of water column. |
Breathing
Attachment: |
Standard Magill's circuit with changeover
unit (open circuit to closed circuit and
vice versa) one no. emergency oxygen outlet
at table level. |
Accessories:
|
Rigid
top tray for monitors; load capacity 20
kg.
One built-iin-self sealing Schrader type
oxygen outlet (4.22 kg/cm2) for driving
ventilators, etc.
Space for ventilator (ventilator at extra
cost)
Circle Absorber (optional) can be securel;y
mounted on the left side of the main frame.
The be ordered with Tubing assembly. |
Dimensions:
cm (approx) |
Hight
- 157 cm Depth - 57 Width - 61 |
Weight:
(approx) |
65
Kg |
