| SPECIFICATIONS |
|
Construction: |
Rust
free aluminum / stainless steel structure with
modern styling. |
| Table
Top: |
Stainless
steel (597mm x 360mm). |
|
Mobility: |
Four
large diameter antistatic castor wheels with
ball bearings and front brakes. |
| Cylinder
Yokes: |
Gas
specific (pin indexed) yokes with sliding stainless
steel clamping bars for easy handling. Two each
for oxygen and nitrous oxide (5 ltr. Water capacity)
[ Cylinders to be ordered separately) . |
|
Pressure
Gauges: |
Large diameter (63 mm), 2 each for oxygen and
nitrous oxide, filted at a convenient angle
for high visibility and clarity. |
| Regulators: |
Double
stage regulators designed for higher efficiency
and service free operation, two each for oxygen
and nitrous oxide. Stainless Steel diaphragms
on high pressure regulation side for service
free operation.
In built hypoxic guard system ensures minimum
23% oxygen in the mix gas and shuts flow of
nitrous oxide when oxygen is closed. |
|
Rotameter: |
2
tube rotameter for oxygen and nitrous oxide.
Ling (230mm) rotating bobbing flowmeters calibrated
in double scale for accuracy and clarity in
reading. |
| Oxygen: |
100 ml / min to 8 liters / min. |
|
Nitrous
Oxide: |
200 ml/min to 12 liters /min. |
| Oxygen
Failure: |
Pneumatic
device which activates audible alarm (for a
minimum of 7 secs) when oxygen supply pressure
fails to 205 kpa. |
|
Vaporizers: |
One Plenum type vaporizer for ether supplied
as stadard. Space for two more vaporizers (Available
at extra cost)
Not Return Cum Pressure relief valve: Minimises
risk of backflow of gases blows off when pressure
exceeds 200 cm of water column in patient circuit. |
| Breathing
Attachment : |
Standard
Magill's circuit with changeover unit (open
circuit to closed circuit and vice-versa). Emergency
oxygen outlet at table level. |
|
Standard
Accessories supplied |
Rigid
top tray for monitors; load capacity 22 kg.
Two build in self sealing Schrader type oxygen
outlets (4-22kg/cm2) for driving ventilators
etc. Tray for ventilator (Ventilator at extra
cost) Circle absorber can be securely mounted
on the leftside of mainframe on the inbuilt
unique designed collapsible type arm. Extended
rear platform for two 10 litre water capacity
cylinders. |
| Dimensions: |
Height
- 150 cm, Depth - 54 cm, Width - 64 cm.
Standard breathing circuit. |
Specifications
are subject to change without notice due to
policy of continuous improvement. |
